Vaillant atmoTEC plus gas wall heater 0010017844
- consisting of electronically controlled pump
- Water pressure sensor and pressure gauge
- 12 l expansion tank
- automatic quick vent and heating safety valve
- Vario frame
- water-cooled
- atmospheric premix burner
- electronic partial load adjustment
- Stainless steel secondary heat exchanger
- hydraulic and gas pre-installation possible
- DIA system with symbol display
- illuminated
- Service panel
- Gas type Natural gas E
- Rated power range 80/60 °C
- 8.0-20.0 kW
- Hot water output 20.0 kW
- Max. heat load for heating: 22.2 kW
- Max. heat load for hot water: 22.2 kW
- Min. heat load 8.9 kW
- Standard efficiency 84% (Hs)/93% (Hi)
- Residual pump head 250 mbar
- Flow temperature max. 85 °C
- Electrical connection 230/50 V/Hz
- Flow/return connection G 3/4
- Cold/hot water connection G 3/4
- Gas connection G 1/2
- Exhaust connection 110 mm
- Height/Width/Depth 800/440/360 mm
- Weight 44 kg
- A high-voltage connection (3~/400V) is required. Approval from the local grid operator may be required. Installation by qualified personnel only.
- Attention: For gas appliances, installation only by qualified personnel
- Attention: The device may only be installed with the original flue gas accessories from Vaillant!!
