Stiebel Eltron hot water wall storage tank 073048 SH 50 S electronic, 50 l, 1-6 kW, white

Stiebel Eltron hot water wall tank 073048

• suitable for supplying hot water to multiple taps (individual and group supply)
• e.g. simultaneous supply of bathroom and kitchen
• Pressure-resistant device for use with all commercially available pressure fittings
• optionally unpressurized to supply a tapping point
• Can be used in single-circuit operation
• Continuous temperature adjustment from approx. 35-82 °C
• The usable heat content is displayed in the control panel by seven LED light fields
• A heating indicator signals the heating operation
• Adjustable three-stage temperature limitation possible
• low energy losses through thermal insulation
• Recyclable construction for environmentally friendly separation of the various components
• Selectable connected load of 1-6 kW with removable strain relief for installation
• Exchange with all common wall storage units
• Recessed grips on the device
• Mounting template for marking the drill holes and pre-installing the water connections
• universal wall mount
• corner mounting is possible
• Also included in the scope of delivery are cover caps for hanging rails and spacers for wall offset
• Installation possible in conjunction with plastic/copper or stainless steel pipe systems
• Signal anode with a directly visible display provides information about the consumption of the magnesium protective anode
• The anode can be changed without removing the flange (50-150 l)
• Removable heating flange with distinctive electrical flange plug
• Protection class IP25 (jet water protected)
• Drainage option through drain valve with hose connection
• Large flange opening for effective and comfortable descaling
• Universal heating flange suitable for single-circuit operation
• Magnesium anode with consumption display via display on the control panel
• Steel inner container with special direct enamel “anticor” for a long service life
• Automatic frost protection monitors the water temperature and protects the container from freezing
• Efficient single-circuit operation with a connected load of 1-6 kW
• Signal anode with light display in the control panel
• replaceable without flange removal (50-150 l)
• with hanging strip
• Drilling template
• Cover caps and spacers
• Radiator connections through complete flange connector
• Drain valve with hose connection

Attention: High voltage connection (3~/400V) required. The consent of the local network operator may be required. Assembly only by qualified specialist personnel
