Möhlenhoff Alpha-Basis direct 8 channel, B 21902-08N2 230V Balance - 8 zones: 230 V, power off-closed (NC) - heating/cooling, pump and boiler control, status signaling

Möhlenhoff Alpha-Basis direct 8 channel, B 21902-08N2 230V

The Alpha direct Balance base station is the intelligent individual room control of the future for maximum comfort and energy efficiency in surface temperature control.

The Alpha direct Balance base station with integrated, TÜV-certified “automatic hydraulic balancing” carries out the balancing from the distribution bar completely independently and without the connection of additional hardware.

The controller signals are also continuously analyzed during operation and changes in the control behavior are implemented.

The heat requirements of the various circuits are recorded by the algorithm, which distributes the opening times of the thermal actuators evenly over a defined period of time. This means that all circuits are supplied with sufficient heat, even in systems that are NOT hydraulically balanced.

The circuits are not supplied with heat at the same time. This function is only used for slow heating systems such as surface heating. Furthermore, the Alpha direct Balance base station can also display cooling by inverting the input signals from standard heating controllers. Commercially available heating room controllers* can be connected. The system recognizes the controller's requirements and adjusts itself automatically. This means that no special heating/cooling controllers are required. Commercially available

• high-quality, modern design

• Differentiation through appearance and function

• Version in 24 V 8 zones/room controller or 230 V 8 zones/room controller

• Integrated TÜV certified “automatic hydraulic balancing”

• Meets the requirements of the Building Energy Act (GEG)

• Eligible for funding by the Federal Office of Economics and Export Control (BAFA)

• Automatic detection of connected controllers

• simple, intuitive installation and operation, without flow and return sensors

• Status indication by LEDs

• Connection for up to 17 actuators

• Initial state NC

• Pump and boiler control

• Connection for dew point sensor and lowering input

• proven cable routing and strain relief

• screwless plug-in/clamping connection technology

• Clearly arranged connection terminals

• High functional reliability

• Maintenance-free

• No initialization or calibration required
