Boiler Aqualift S lifting system 280500SC
- plastic
- with free-flow impeller
- a pump type GTF
- removable
- Float circuit
- System ready to plug in
- Socket for inlet and cable conduit
- Telescopic attachment piece with integrated drain function and flange for sealing in the composite
- Pressure line DN 32/DA 40
- Pump GTF 500 usable volume 16 l/flow rate max. 10 cbm/h/delivery height max. 8 m
- Pump GTF 1200 usable volume 16 l/flow rate max. 155 cbm/h/delivery height max. 9 m
- Pump GTF 500 resistant resistant to saline media/wastewater from softening systems as well as condensate-containing wastewater from heating systems
- Class K 3
- Cable length 5 m
- Installation depth 490-620 mm
- Recess dimensions 700 × 700 mm
