- made of PE to accommodate a type U3KS drainage pump
- U5KS
- U3KS special
- U6K ES/DS
- US 62ES/DS
- US 102ES/DS
- US 73 ES/DS or US 103 ES/DS
- designed for the disposal of faecal-free waste water above and below the backflow level
- Eg water from washing machines and vanities
- Dirty water from commercial operations and condensate from gas condensing boilers
- Disposal of a shower tray installed at ground level is possible with the U3KS in connection with a special float for low switching heights
- Tank is equipped with 4 lateral combination inlets DN 100/DN 50
- 2 of which are on a low level for connecting a shower tray
- buoyancy protection
- pump lock
- two recessed grips
- Container lid with pre-assembled seal and snap lock
- can be dismantled without tools
- Cover for odour-tight cable entry with cable strain relief and ventilation valve with activated carbon filter
- all necessary parts of the tank pressure line are loosely enclosed
- with elastic connection for sound-insulating, flexible connection and quick-release screw connection for tool-free dismantling of the pump
- Pressure line not pre-assembled
- for optimal adaptation to on-site installation conditions
- Pressure outlet on the container is pre-centered on both sides
- Version as threaded nipple 1 1/2'
- Also included in the scope of delivery: plug-in seal DN 50
- Connection sleeve DN 100 made of EPDM with 2 pipe clamps 4'
- and non-return valve DN 40 with 2x IT 1 1/2'
- Alarm system and washing machine stop available as accessories
- with battery also independent of the mains
- Container volume: approx. 75 l
- 500x570x390mm
- Weight: about 8
- 6kg
Jung Hebefix above-ground tank JP09348 100 H, for hot water, without pump
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 1100
Part Number: JP09348
Questions about the article?
+49 241-51832611
Mon. - Thu. 8.00 am to 6.00 pm, Fri. 8.00 am to 3.00 pm
Details
Jung Hebefix above-ground container JP09348
Notice
Please note that gas and electric appliances require increased mains voltage for proper operation. These appliances are not equipped with a two-pin mains plug. The installation of non-pluggable appliances must be carried out by the respective network operator or a certified specialist company, which can also assist you in obtaining any necessary approval from the relevant network operator for the installation of the appliance.
