ABB Stotz PS3/12 busbar 2CDL231001R1012
- ABB busbars enable the safe and economical cross-wiring of circuit breakers.
- Residual current devices and other modular installation equipment. For correct busbar selection, the following must be observed: Terminal type (double terminal or cage clamp)
- Number of poles of the devices (1, 2, 3, 4, 1+N or 3+N)
- Device type (circuit breakers, residual current devices or modular installation devices)
- Combinations of different device types, use of circuit breakers with auxiliary switches mounted on the right and bottom, busbar connection cross-section (current carrying capacity)
- Number of modules (selection from standard busbars or cuttable busbars)
- 1+N or 3+N)
- Device type (circuit breakers)
- Residual current protective devices or modular installation devices)
- Combinations of different device types
- Use of circuit breakers with auxiliary switches mounted on the right and bottom.
- Busbar connection cross-section (current carrying capacity)
- Number of modules (selection from standard busbars or cuttable busbars)
